55 inch LCD Display Panel for Samsung - LTI550FN01
Large LCD Screen LTI550FN01 for Digital signage
55 inch LCD Panel LTI550FN01 for Digital signage

55 inch LCD Display Panel for Samsung - LTI550FN01

Product Specification:
  • Model : LTI550FN01
  • Size : 55 inch
  • Resolution : 3840(RGB)×2160 [UHD]
  • Brightness : 500 cd/m² (Typ.)
  • Application : Digital Signage, Public Information Display (PID)
Inquiry
  1. Product Details
  2. Download
Description of LTI550FN01


55 inch LCD Display Panel for Samsung - LTI550FN01



Lable of LCD Display panel LTI550FN01



Stock Quantity 1200 pcs
Warranty 18 months
Quality A grade Samsung original & brand new,factory-seal package
Delivery Period 1 Day
MOQ 1 pc





DESCRIPTION



LTI550FN01 is a color active matrix liquid crystal display (LCD) that uses amorphous silicon TFT (Thin Film Transistor) asswitching components.



This model is composed of a TFT LCD panel, adrivercircuit, and a backlight unit.



This 55 inch model has a resolution of 3840x2160 pixels (16:9) can display up to 16.7 Million colors with the wide viewing angle of 89 or higher in all directions.



FEATURES



RoHS compliance (Pb-free)
UHD (3840x2160) resolution (16:9)
SVA(Super Vertical Align) mode
High Tni(85℃) Liquid Crystal
High speed response
High contrast ratio, High aperture ratio with the widec olor gamut
Wide viewing angle(±178°)
Landscape / Portrait type compatible
V-by-One Interface (16Lanes @ 3840x2160)
DE(Data Enable) mode
Edge LED Backlight
Low power consumption
Black Mura Improvement Technology





APPLICATIONS



Public Information Display(PID) (If there is the intent to use this product for other purpose, please contact JFCVision.)





Panel Model LTI550FN01
Size 55 inch
Resolution 3840(RGB) ×2160, UHD
Brightness 500 cd/m² (Typ.)
Aspect Ratio 16:10 (W: H)
Surface Antiglare (Haze 25%), Hard coating (2H)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10)
Contrast Ratio 4000:1 (Typ.) (TM)
Response Time 6 (Typ.)(G to G)
Signal Interface V-by-One 16 lane, 92 pins, Connector
Frequency 120Hz
Lamp Type WLED, 50K hours, With LED Driver
Application Digital Signage, PID
Carton 20 pcs/carton
Size:  1440×1120×769 mm(without pallet plastic)



Response Time of 55 inch LCD Panel

Contrast Ratio of 55 inch LCD Panel

Haze 25%, Anti-glare of 55 inch LCD Panel

7*24 Operating of 55 inch LCD Panel LTI550FN01





4K 120Hz UHD (3840*2160)



High Definition, Exquisite Picture, Ultra HD Resolution 3840*2160



Large LCD panel





120Hz Ultra High Refresh Rate, Clear Capture, More Pictures More Joys



4K 55 inch lcd panel





Contrast:4000:1  S-RGB



Clear and conspicuous image, excessively natural details and widely color gamut, vivid picture and bright color

Contrast is 4000:1 of  55 inch LCD Display Panel - LTI550FN01



High contrast ratio with clearly shadow picture



           High contrast ratio of  Large LCD Screen -LTI550FN01



Structure of LTI550FN01



Ultra-thin screen:The thickness of the side of the LCD panel





Multi screw holes, multi selective for accessories and installation method



Structure of 55 inch LTI550FN01 LCD Display Panel

55 inch LCD Display Panel for Samsung - LTI550FN01



Customized Solution (SKD)

2K Program

2K AD board for LTI550FN01

Converter for Large LCD Screen

Power board for LCD Display Panel

2K AD board Converter Power board

4K Program

4K AD board for LTI550FN01 55 inch LCD Panel

4K Converter for 55 inch LCD Panel

Power board 55 inch Large LCD Screen
4K AD board 4K Converter Power board
