LG LCD Panel

LG LCD Panel

LG 43 inch 700 nit Full View Angel LCD Panel Supplier - LD430EUE-FHA1
LG 43 inch LCD Panel Supplier LD490EUE-FHA1
43 inch LCD Panel Supplier LD490EUE-FHA1

LG 43 inch 700 nit Full View Angel LCD Panel Supplier - LD430EUE-FHA1

Product Specification:
  • Model : LD430EUE-FHA1
  • Size : 43 inch
  • Resolution : 1920(RGB)×1080 , FHD
  • Brightness : 700 cd/m² (Typ.)
  • Application : Digital Signage
Inquiry
  1. Product Details
Product Description





LG 43 inch 700 nit Full View Angel LCD Panel Supplier - LD490EUE-FHA1

LCD Panel Supplier - LD490EUE-FHA1



General Description



The LD430EUE is a Color Active Matrix Liquid Crystal Display with an integral Light Emitting Diode (LED) backlight system.
The matrix employs a-Si Thin Film Transistor as the active element.
This LCD panel is a transmissive display type which is operating in the normally black mode.
This LCD panel has a 43.0 inch diagonally measured active display area with WUXGA resolution (1080 vertical by 1920 horizontal pixel array).
Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arrayed in vertical stripes.
Gray scale or the luminance of the sub-pixel color is determined with a 8-bit gray scale signal for each dot. Therefore, it can present a palette of more than 16.7Milion colors.
This LCD panel has been designed to apply the 8-bit 2-port LVDS interface.
This LCD panel is intended to support Commercial Display where high brightness, super wide viewing angle, high color gamut, high color depth and fast response time are important.



Specifications
Part Number: LD430EUE-FHA1   Lamp Type: S-IPS, Normally Black, Transmissive
Size: 43 inch   Signal Interface: LVDS (2 ch, 8-bit) , 51 pins , Connector
Resolution: 1920(RGB)×1080 , FHD   Surface: Antiglare (Haze 1%), Hard coating (3H)
Contrast Ratio: 1100:1 (Typ.) (TM)    Storage Temp.: 0 ~ 50 °C
Brightness: 700 cd/m² (Typ.)   Operating Temp.: -20 ~ 60 °C
Viewing Angle: 89/89/89/89 (Typ.)(CR≥10)    Weight: 7.50Kgs (Typ.)
Frequency: 60Hz   Application: Digital Signage
Original Package
Package quantity in one Pallet
Pallet size



Customization
Item Customization MOQ
Touch panel size, silk print, touch signal connector MOQ is different based upon different sizes
Cover lense hardness, thickness, sizes, shape, color <21.5'', 200pcs
≥21.5'', 100pcs
≥32'', 50pcs
LCD Panel Brightness NO
Bonding air bonding or optical bonding NO
Boards AD board with different signal connectors
PC boards with different systems and functions
for different application
Customized logo added
NO
Cables Signal connector PIN ID
Length
NO




You Many Also Like?





Panel Model Panel Brand Size Resolution Frequency Brightness
LD320DUE-FHB1 LG 32 1920*1080 60Hz 400nit
LD430EUE-FHB1 LG 43 1920*1080 60Hz 450nit
LD430EUE-FHA1 LG 43 1920*1080 60Hz 700nit
LD490EUE-FHB1 LG 49 1920*1080 60Hz 450nit
LD490EUE-FHA1 LG 49 1920*1080 60Hz 700nit
LD550EUE-FHB1 LG 55 1920*1080 60Hz 450nit
LD550EUE-FHA1 LG 55 1920*1080 60Hz 700nit
LD550EQE-FKA1 LG 55 4K 60Hz 500nit
LD490EQE-FKA1 LG 49 4K 60Hz 500nit







For choose more suitable screen or more information about product please click to contact us!

LCD Panel Supplier - LD490EUE-FHA1





Warehouse Overview

Warehouse of LG LCD Panel Supplier - LD490EUE-FHA1







Why Choose Us?

1. Large Stock System:
We have our own warehouses in Shenzhen, and Hongkong, with comprehensive supplying network of LCD panels & open cells for LG, Samsung, AUO, CMO, and other brands.

2. Comprehensive Panel sources.
We have strong ability and system to seek for our customers the panels which have been end of production for a long time.

3. Professional acknowledgment of LCD panels industry to provide customers with effective advice.
We have been in original LCD panels industry for more than 10 years and know the main brands' LCD panel price system very well. What's more, we have our own engineer team to provide our customers guideline for choosing panels for their new projects.

4. During the warranty, if panels’ electronic functions problems occur, customers provide the photos to illustrate the panel’s problem. Once our engineering department has confirmed it is the original factory’s electronic problem, we will take back the panels with problem and replace it with new panels. All freight will be taken by us.







Warranty



1. All panels’ grade is promised strictly same as original factory’s IIS standard.

2. All brand-new Panels’ electronic functions are guaranteed during warranty period of 1 year beginning with the invoice date.

3. We can do OEM of the High Brightness LCD module as required.







 FAQ


Q1: Any discount?
A1: We will try our best to provide you the competitive price and good service.



Q2: Are you a manufacturer?
A2: Yes, we are a manufacturer of capacitive touch screen.


Q3: What about the warranty of the products?
A3: 12months after delivery. During the warranty, if panel's original factory problems occur, we will take back the panels with problem and replace it with new panels.
All freight will be taken by us.


Q4: What about the payment terms?
A4: T/T, Paypal, or Western Union


Q5: Can you accept OEM or ODM orders?
A5: Yes, we are a touch screen manufacturer, with professional structural,
QC and technical engineers provide OEM or ODM service.


Q6: How to ensure the safety of the screen in transportation?
A6: In order to keep screen in safe, plywood wooden box will be used to pack
 the TFT LCD Display Module.


Q7: If I need customized capacitive touch screen, what can you do for me?
A7: Confirm your requirements (size, resolution, brightness, application, operation
environment), after information confirmed → design drawing → produce sample → sample
test, QC report → prepare instruction manual → ship.
