LG LCD Panel
LG 98 inch 120Hz 4K 500 nit LCD Panel Manufacturers - LD980DQD-FGM1
- Model : LD980DQD-FGM1
- Size : 98 inch
- Resolution : 3840(RGB)×2160 , UHD
- Brightness : 500 cd/m² (Typ.)
- Application : Digital Signage
Product Description
General Description
The LD980DQD is a Color Active Matrix Liquid Crystal Display with an integral Light Emitting Diode(LED) backlight system.
The matrix employs a-Si Thin Film Transistor as the active element.
The LCD panel is a transmissive display type which is operating in the normally black mode.
The LCD panel has a 97.52 inch diagonally measured active display area with QWUXGA resolution (2160 vertical by 3840 horizontal pixel array).
Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arrayed in vertical stripes.
Gray scale or the luminance of the sub-pixel color is determined with a 10-bit gray scale signal for each dot. Therefore, The LCD panel can present a palette of more than 1.06 Bilion colors.
The LCD panel has been designed to apply the 10-bit 16 Lane V by One interface.
The LCD panel is intended to support LCD TV, PCTV where high brightness, super wide viewing angle, high color gamut, high color depth and fast response time are important.
| Specifications | ||||
| Part Number: | LD980DQD-FGM1 | Lamp Type: | S-IPS, Normally Black, Transmissive | |
| Size: | 98 inch | Signal Interface: | V-by-One 16 lane , 97 pins , Connector | |
| Resolution: | 3840(RGB)×2160 , UHD | Surface: | Antiglare (Haze 1%), Hard coating (3H) | |
| Contrast Ratio: | 1300:1 (Typ.) (TM) | Storage Temp.: | 0 ~ 50 °C | |
| Brightness: | 500 cd/m² (Typ.) | Operating Temp.: | -20 ~ 55 °C | |
| Viewing Angle: | 89/89/89/89 (Typ.)(CR≥10) | Weight: | 56.0/59.0Kgs (Typ./Max.) | |
| Frequency: | 120Hz | Application: | Digital Signage | |
| Original Package | ||||
| Package quantity in one Pallet | 4 pcs | |||
| Pallet size | 2500mm(W) X 760mm(D) X 1574mm(H) | |||
| Customization | ||
| Item | Customization | MOQ |
| Touch panel | size, silk print, touch signal connector | MOQ is different based upon different sizes |
| Cover lense | hardness, thickness, sizes, shape, color | <21.5'', 200pcs ≥21.5'', 100pcs ≥32'', 50pcs |
| LCD Panel | Brightness | NO |
| Bonding | air bonding or optical bonding | NO |
| Boards | AD board with different signal connectors PC boards with different systems and functions for different application Customized logo added |
NO |
| Cables | Signal connector PIN ID Length |
NO |
