55 inch OLED Screen Display For LG Display - LW550PUL-HLA3
OLED-Screen-LW550PUL-HLA1

55 inch OLED Screen Display For LG Display - LW550PUL-HLA3

Product Specification:
  • Model : LW550PUL-HLA3
  • Size : 55 inch
  • Resolution : 1920(RGB)×1080 [FHD]
  • Brightness : 400 cd/m² (Typ.)
  • Color gamut : -
  • Touch work ability : -
  • Application : -
Inquiry
  1. Product Details
Specifications
Panel Model LW550PUL-HLA3
Panel Size 55 inch
Resolution 1920(3) ×1080, FHD
Display Area 1209.6(W)×680.4(H) mm
Outline Size 1217.48(W)×693.74(H) mm
Brightness 400 cd/m² (Typ.)
Viewing Angle 60/60/60/60 (Min.)
Best View on Symmetry
Display Colors 1.07B   89% NTSC
Frequency 120Hz
Panel Weight 2.40Kgs (Typ.)
Signal Interface V-by-One 8 lane, 65 pins, Connector
Input Voltage 12.0/24.0V (Typ.)(VDD/EVDD)
Environment Operating Temp.: 0 ~ 45 °C ; Storage Temp.: -20 ~ 60 °C
Panel Type AM-OLED, OLED
Pixel Format RGBW Vertical Stripe
Surface Hard coating (2H), Reflection 1.2% (Typ.)
Contrast Ratio 150000:1 (Typ.) (TM)
Response Time 1 (Typ.)(G to G); 8 (Typ.)(MPRT)
Lamp Type self, 30K hours
Touch Screen Without
Application TV Sets
